Platform
|
APC Instruments |
|
Industry Standards
|
ISO 21501-4 ISO 14644-1:2015 FCC CE |
|
Light Source
|
Long Life Laser™ Diode |
|
Particle Size Analysis Range
|
0.5 to 10 μm |
|
Flow Rate
|
28.32 L per minute |
|
Coincidence Loss
|
10% at 20,000,000 particles/m³ |
|
Sample Volume
|
10 µm |
|
Throughput
|
28.32 L per minute |
|
Data Storage
|
1,000 samples (oldest records overwritten when buffer is full) |
|
Threshold Setting
|
0.5 µm |
|
Pump Type
|
Air vacuum, rated for continuous use |
|
Zero Count
|
ISO 21501-4 & JIS B 9921 (1 count or less in 5 min, 95% UCL) |
|
Count Alarms, Display & Cycles
|
User-defined alarm counts displayed via LED on box or remote LED |
|
Environmental Conditions
|
Indoor Environment |
|
Power Requirements
|
0.4 A Max, 100-240 VAC, 50/60 Hz |
|
Operating Modes
|
Automated or remote sampling |
|
Weight
|
4.6 kg |
|
Width
|
17.2 cm |
|
Depth
|
31.8 cm |
|
Height
|
11.5 cm |
|
Color
|
Silver |
|
Package Quantity
|
1 |
